Description

Key Steering Solutions:

Electronic Command Steering (ECS)

Hypro Marine’s Electronic Command Steering (ECS) system offers the same responsive performance as hydraulic steering but with a simpler, more efficient installation process.

Features:

• No hydraulic hoses or oil running to helm positions, eliminating potential for costly accidents.
• A single pre-made wiring harness with Deutsch multi-pin connectors replaces hydraulic lines.
• Simplified installation reduces time for commissioning.
• 4 turns lock-to-lock steering at 1 second per revolution response rate, with a positive lock at hard over.
• Multi-station capable and designed for vessels 40 feet and larger, scalable for yachts over 100 feet.
• Options for tilt helm and rear or front mount fixed helm.
• No rudder feedback device required.
• Emergency backup available.

Benefits:

• Faster, cleaner installation.
• Reduced risk of hydraulic leaks.
• Improved reliability and quicker system setup.

12/24 Volt DC Powered Steering

The 12/24V DC power pack systems are one of the latest power-assisted steering options from Hypro Marine. These systems are valued for their simplicity and ease of installation, making them increasingly popular for a variety of vessels.

Features:

• Originally introduced on the smaller HM2940 Servo Power Cylinder, now available for larger applications.
• Multi-station capable and non-pressurized, allowing vented upper helm.
• Manual bleeding or use of a 12V automatic power purger for efficient commissioning.
• Automatic reversion to manual wheel steering in case of power loss.

Pressurised Engine/Gear Box PTO Pump Driven Steering

Hypro Marine has long produced pressurised direct drive pump systems, which have been continuously improved and upgraded over time.

Features:

• Pumps compatible with most popular engine and gearbox models, with an option for pre-installed units.
• Can be configured with single or twin pumps and a pressure and flow conditioning valve to suit various vessel types.
• Multi-station capable with pre-charged pressure, providing 3½ turns lock-to-lock steering with fingertip control.
• Includes an autopilot control valve as part of the bulkhead reservoir.
• In the event of power loss, the system automatically reverts to manual steering.

Arneson Surface Drive Control

Hypro Marine has extensive experience in supplying steering systems for Arneson Surface Drives, supporting configurations of up to triple ASD 16s, including trim control.

Why Choose Hypro Marine Steering Systems:

• Unmatched reliability in challenging marine environments.
• Trusted by leading yacht builders, Coast Guard agencies, and rescue organizations.
• Offers versatile, innovative solutions such as ECS, DC power steering, and pressurised pump systems for a wide range of vessels.
• Superior steering performance with cutting-edge technology and simplified installation.
